Vertical Carton Case Packer Machine Case packing system line
This equipment is an intelligent grab-type cartoning machine. It uses high-speed dispensing device to pack various containers, and can pack plastic flat bottles, round bottles, special-shaped bottles, and glass bottle boxes of various sizes.
●Clamp the bottle body (1-4 boxes at a time) by the bottle clamp (built-in rubber to prevent damage to the bottle body), put it into the opened carton, when the gripping head is lifted, the carton is discharged and sent to the sealing machine (This packing method also applies to other products such as boxes).
●This machine adopts Mitsubishi PLC + touch screen control. Equipped with safety devices such as material shortage alarm and shutdown, no material without packing and other safety devices.
●This equipment greatly facilitates operation and management, reduces production personnel and labor intensity, and is an essential equipment for automated large-scale production.
●All electrical components are selected from international brands, and the performance of the whole machine is stable and reliable.
●Fast packing speed, suitable for large-volume, high-speed assembly line automatic packing operations.
| Model | XQ-ZX400L |
| Packing Size | L 250-550mm; W 150-400mm; 150-400mm; Customized |
| Production Capacity | Max. 6 downloads/carton, and loading 4 cartons at the same time per minute. |
| Product loading method | Top-loading |
| Total Power | 2.3KW |
| Working Voltage | 380V/ 50Hz |
| Air pressure source supply | 5.5~6kg/cm2 |
| Machine Dimensions | L2130 mm ×W2050 mm ×H3200 mm. depend on customized |
| N.W | 1000KG, depend on customized |
| Note: For Customized product, all data above are for reference only, the final data are subject to actual demand. |
●The main production cartoning machine runs smoothly and reliably, the packaging effect is firm and beautiful, and the configuration is high. The main components are selected from international famous brand equipment, which is easy to operate and easy to maintain.
●Automatic control: The control system is the guarantee for the normal operation of all functions, as well as the automatic protection for failures and accidents.
●Adopt oil-free pneumatic components, with low noise and no oil pollution.
●Especially suitable for use with packaging line, easy to move.
●It has a wide range of applications, and it adopts multiple sets of box bottom positioning and blocking devices, which can be applied to packing a variety of products.
●Adopt frequency conversion speed regulation and PLC control technology, combined with man-machine interface, easy operation and high degree of automation.
●According to the packing requirements, the products can be automatically arranged and arranged, the movements are coordinated, the movement is stable and accurate
●It is equipped with a safety device that alarms and stops when there is no bottle.
